Bead Filters |
| || || | | || || || || |
|
|
Bead Filters |
|
|
|
|
|
Specifications : |
BF 100 |
BF 250 |
BF 500 |
BF 1000 |
|
Material : |
Food Grade Fibreglass |
Food Grade Fibreglass |
Food Grade Fibreglass |
Food Grade Fibreglass |
|
Capacity : |
Recirculation 2,000 litres |
Recirculation 5,000 litres |
Recirculation 10,000 litres |
Recirculation 20,000 litres Pond 60,000 litres |
|
Media : |
.027m^3 / 1ft^3 |
.054m^3 / 2ft^3 |
.108m^3 / 4ft^3 |
.216m^3 / 8ft^3 |
|
Dimensions : |
900 H x 600w |
1100 H x 600w |
1200 H x 660w |
1800 H x 1000w |
|
Flow Rate : |
100 L/Min - 6000L/Hr |
170 L/Min - 10200L/Hr |
300 L/Min - 18000L/Hr |
600 L/Min - 36000L/Hr |
|
Pressure : |
Max 100 kpa |
Max 100 kpa |
Max 100 kpa |
Max 100 kpa |
|
Back flush loss : |
60 Litres |
100 Litres |
110 Litres |
150 Litres |
|
Inlet : |
25mm Slip |
25mm Slip |
32mm Slip |
50mm Slip |
|
Outlet : |
25mm Slip |
25mm Slip |
32mm Slip |
50mm Slip |
|
Waste : |
25mm Slip |
32mm Slip |
40mm Slip |
50mm Slip |
Key benefits:
Extra strong due to moulded fibreglass construction
Can be matched to tanks for a fully integrated recirculation package
Low outlay cost and easy maintenance
Full after sales back up available
|
